PMX2

The PMX-2 is an AM/FM/WP tuner and compact digital media receiver with a 2.7" full color display.

The PMX-2 compact digital media receiver is designed for marine and motorsports applications. The PMX-2 features a 2.7"full color TFT display for optimum viewing - even in full sun - that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such Pandora control capabilities and Bluetooth audio steaming with album art support for Apple and Android products, this unit becomes a true command center of any system.

Output flexibility comes with a 4x50W @ 2ohm internal amplifier or front and rear/sub output RCA's allowing the addition of after-market amplifiers for more power and output. Add-in the EEPROM memory system, custom GUI interface, and wired remote expansion capabilities and you have the only media receiver you'll ever need.

Features:

• ISO8846/SAE J1171 Ignition Protection Certified
• Pandora Internet Radio
• A2DP and AVRCP Bluetooth Wireless Streaming
• FCC, CE, IC, and C-Tick Certified
• Multi Region Radio Frequencies
• Low Voltage Warning Alert
• AUX and USB Inputs with USB Charging
• On Board Punch EQ Control
• iPod playback with on-screen display
• Independent Subwoofer Level Control
• Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
• IPX6 Marine Grade
• 7-Band Graphic EQ
• 2.7" full color display w/ auto dimming backlightning
• AM / FM / WB Tuner
• Zone Control: 1 Zone / 1 Source (F/R or Sub)
  *Antenna not included

Specifications:

• FM Tuner:
  • Sensitivity: 8 dB
• AM Tuner:
  • Frequency Range: 530 kHz - 1710 kHz
• AM Tuner:
  • Usable Sensitivity: 40 dB
• RCA Output Voltage: 4 V
• RCA Output Impedance: 500Ω
• Operating Voltage: 10.5 V - 16 V
• Speaker Impedance: 2-Ohms
• Fuse Rating: 20 A
• USB Capacity:
  • 32Gb max
  • 999 Folders max
  • 999 Songs max
• Media Player:
  • Audio Format Compatibility: MP3, WMA
• Compatible Remotes:
  • PMX-1R
  • PMX-0R
  • (3 Remote Limit, 100 ft Total Wired Distance)
• Android Compatibility: Bluetooth® Only
• Device Type: Digital-Media Receiver
• Pandora® Internet Radio (Yes/No): Yes
• Bluetooth® (Yes/No):
  • Yes
  • 3.0+EDR, A2DP 1.3
• WB Tuner:
  • Frequency Range: 162.40 - 162.55 (US & Canada)
• Tuner:
  • Number Of Presets: 18 FM / 12 AM / 6 WB
  • USB Version: 2.0
  • USB Charging (Yes/No): Yes
  • Steering Wheel Control Ready (Yes/No): No
  • Frequency Response: 20 Hz - 20 kHz
  • Multi-Zone/Multi-Source (Yes/No): No
• FM Tuner:
  • Frequency Range: 87.5 MHz - 107.9 MHz
  • Power Output:
    • CEA-2006 Guidelines CEA-2006 Power Rating:
      • 25W x 4 @ 4Ω RMS
      • 50W x 4 @ 2Ω Peak
      • ≤1.0% THD+N
  • Clock (Yes/No): Yes
  • Speaker Outputs (Yes/No): Yes
  • Made for iPod Models:
    • iPod Touch (5th generation)
    • iPod Touch (4th generation)
    • iPod Nano (7th generation)
    • iPod Nano (6th generation)
• Display Size: 2.7" Color TFT
• SiriusXM-Ready® (Yes/No): No
• USB Output Current: 1A
• Apple®/Android™ Compatible (Yes/No): Yes
• AUX Input (Yes/No): Yes

Approximate Dimensions:

• Height: 4.2"
• Width: 4.5"
• Face Depth: 1.5"
• Mount Depth: 2.9"
