M2-10HB
M2-10HB
The next evolution of on-water audio, the M2 10-inch wake tower speakers create an unmatched audio experience with class-leading output, full on-water lighting control and grille customization.
Features and Benefits:
Color Optix™: Adjust your own bright, wide and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play controller and app (sold separately).
Element Ready™: Purpose built for the marine environment, Rockford's Element Ready™ products are built to stand up to water, salt and UV, ensuring your speakers stand the test of time.
Infinite Customization: Multiple grill options designed to dial in your personal on-the-water experience.
True Marine Ecosystem:Dual integrated Deutsch™ / Amphenol™ connections provide industry-leading marine plug-and-play connectivity and flexible install options.
Features at a Glance
- Integrated 1” (25 mm) high efficiency horn tweeter
- 1" (25mm) High Temperature Kapton™ Woofer Voice Coil Pre
- Injection-molded frame with ultra-high temperature PA66 30% glass fill with UV inhibitors
- Proprietary Dual Function Input Terminal
- Gold plated marine grade brass terminals provide a corrosion resistant connection
- Integrated Deutsch RGB and speaker receptacles
- 100% UV Stabilized Centrex Plastic Grill
- Moisture, tear and fatigue resistant aramid fiber spider
- Vented motor design with water-repelling nano coated mesh screen
- Fully insulated flex lead wire stitched under spider
- UV and salt-fog resistant TPE (thermo-plastic elastomer) surround
- VAST vertical attach surround technology increases the effective radiated cone area by up to 25%
- Injection molded mineral filled polypropylene cone body with UV inhibitors
- co-molded surround and taper body
- 12dB/octave crossover network
- Fully sealed Integrated Concealed Crossover (ICC) network
- metallized polyester film capacitor
- Optically Clear UV Stabilized Encapsulated LED PCB
- multiplex rgb input
- Ultra-bright, wide angle tri-color surface mount LED with flat molded lens
Specifications | ||
---|---|---|
Sensitivity | 97 dB at 2.83 volts 94 dB at 1 watt |
|
Frequency Response | 20 - 25k Hz | |
Max RMS Power Handling | 300 | |
Peak Power Handling (Watts) | 1200 | |
Impedance (Ohms) | 4 | |
Top-mount Depth (Inches) | 4 11/16 | |
Bottom-mount Depth (Inches) | N/A | |
Cutout Diameter or Length (inches) | 9 1/4 | |
Bolt Circle | 10.058 |
